ANDI UPDATE
Flare Stack Model:
BGR-FS0086
-
Constructed under ISO 9001-2008 quality control system
-
Destruction removal efficiency 98% and meets requirements of EPA NSPS 40 CFR Part 60 Sub Part 0000 & AER directive 60
-
May be operated with or without continuous pilot
-
24” x 8” x 6” x 40’ high-free standing (optional guy wires available)
-
Fully retractable pilot ignition system with 1400lb winch with 5/32 aircraft cable
-
Stainless steel flare tip
-
Estimated approximate flow rate 5 mmscfd
-
Detonation flame arrestor required (not included)
-
Purge reducer
Stack Size
& Specification
Controller
Specification
-
CSA approved ACL 3200 Ignition Control System (meets CSA B149.3-10)
-
Monitors and controls ignition
-
Remote stop and start
-
Auto re-light, continuous trial for ignition
-
Thermocouple and thermowell for temperature sensing and monitoring
-
Solar operated 12/24 VDC
-
Modbus built in for remote communication
-
Data logging & acquisition to meet EPA requirements
ANDI UPDATE
Flare Stack
Model: BGR-FS1284
-
Constructed under ISO 9001-2008 quality control system
-
Destruction removal efficiency 98% and meets requirements of EPA NSPS 40 CFR Part 60 Sub Part 0000 & AER directive 60
-
May be operated with or without continuous pilot
-
24” x 8” x 6” x 40’ high-free standing (optional guy wires available)
-
Fully retractable pilot ignition system with 1400lb winch with 5/32 aircraft cable
-
Stainless steel flare tip
-
Estimated approximate flow rate 5 mmscfd
-
Detonation flame arrestor required (not included)
-
Purge reducer
Stack Size
& Specification
Controller
Specification
-
CSA approved ACL 3200 Ignition Control System (meets CSA B149.3-10)
-
Monitors and controls ignition
-
Remote stop and start
-
Auto re-light, continuous trial for ignition
-
Thermocouple and thermowell for temperature sensing and monitoring
-
Solar operated 12/24 VDC
-
Modbus built in for remote communication
-
Data logging & acquisition to meet EPA requirements
ANDI UPDATE
Flare Stack
Model: BGR-FS1286
-
Constructed under ISO 9001-2008 quality control system
-
Destruction removal efficiency 98% and meets requirements of EPA NSPS 40 CFR Part 60 Sub Part 0000 & AER directive 60
-
May be operated with or without continuous pilot
-
24” x 8” x 6” x 40’ high-free standing (optional guy wires available)
-
Fully retractable pilot ignition system with 1400lb winch with 5/32 aircraft cable
-
Stainless steel flare tip
-
Estimated approximate flow rate 5 mmscfd
-
Detonation flame arrestor required (not included)
-
Purge reducer
Stack Size
& Specification
Controller
Specification
-
CSA approved ACL 3200 Ignition Control System (meets CSA B149.3-10)
-
Monitors and controls ignition
-
Remote stop and start
-
Auto re-light, continuous trial for ignition
-
Thermocouple and thermowell for temperature sensing and monitoring
-
Solar operated 12/24 VDC
-
Modbus built in for remote communication
-
Data logging & acquisition to meet EPA requirements
ANDI UPDATE
Flare Stack
Model: BGR-FS2486
-
Constructed under ISO 9001-2008 quality control system
-
Destruction removal efficiency 98% and meets requirements of EPA NSPS 40 CFR Part 60 Sub Part 0000 & AER directive 60
-
May be operated with or without continuous pilot
-
24” x 8” x 6” x 40’ high-free standing (optional guy wires available)
-
Fully retractable pilot ignition system with 1400lb winch with 5/32 aircraft cable
-
Stainless steel flare tip
-
Estimated approximate flow rate 5 mmscfd
-
Detonation flame arrestor required (not included)
-
Purge reducer
Stack Size
& Specification
Controller
Specification
-
CSA approved ACL 3200 Ignition Control System (meets CSA B149.3-10)
-
Monitors and controls ignition
-
Remote stop and start
-
Auto re-light, continuous trial for ignition
-
Thermocouple and thermowell for temperature sensing and monitoring
-
Solar operated 12/24 VDC
-
Modbus built in for remote communication
-
Data logging & acquisition to meet EPA requirements
All Rush Industries flare stacks are built to provide the quality assurance and reliability to meet today’s rigorous conditions. Our flare tips are designed and engineered to provide years of trouble-free operation.
With operator safety and ease of use at the forefront of every design Rush Industries ensures stable high efficiency flaring through an entire range of flow rates and conditions, while our retractable ignition systems and easy to use CSA approved controllers ensure operator comfort and safety.
​
With a strong team of experienced professionals, Rush Industries continually exceeds client’s expectations by focusing on safety, innovation, and environmental stewardship.
​
Rush Industries operates under the ISO 9001:2008 quality control system.
